RF Power Amplifier - 200W - 2GHz - 6GHz
The EMC2G6G53C is a broadband high-power amplifier operating between 2 GHz and 6 GHz, offering a wide dynamic range with 200 Watts typical saturated power. Powered by advanced GaN solid-state technology, it ensures state-of-the-art power performance with excellent power-to-volume ratio, ideal for broadband high-power applications.
Technical Specs
| Model | EMC2G6G53C |
|---|---|
| Manufacturer | EMCTEST Technologies |
| Conditions | Brand New |
| Frequency | 2GHz - 6GHz |
| Power | 200W |
| Gain | 53 dB |
| Impedance | 50 Ω |
| Cooling | Forced Air |
| Connector Type | N-Type Precision Female |
| Dimensions | 485 × 482 × 180 mm |
| Weight | 20 Kg |
| Operating Temperature | -40°C +60°C |
| Power Supply | 100–240 V @ 50/60 Hz |
| EMC Test Standards |
